SwiftUI GeometryReader for dynamic layouts

Sofia Martinez Jan 2026
1 tab
import SwiftUI

struct ResponsiveGridView: View {
    let items: [GridItem]

    var body: some View {
        GeometryReader { geometry in
            let columns = calculateColumns(for: geometry.size.width)
            let spacing: CGFloat = 16
            let itemWidth = (geometry.size.width - spacing * CGFloat(columns + 1)) / CGFloat(columns)

            ScrollView {
                LazyVStack(spacing: spacing) {
                    ForEach(items.chunked(into: columns), id: \.self) { row in
                        HStack(spacing: spacing) {
                            ForEach(row) { item in
                                GridItemView(item: item)
                                    .frame(width: itemWidth, height: itemWidth)
                            }

                            // Fill remaining space if row is incomplete
                            if row.count < columns {
                                ForEach(0..<(columns - row.count), id: \.self) { _ in
                                    Color.clear
                                        .frame(width: itemWidth, height: itemWidth)
                                }
                            }
                        }
                    }
                }
                .padding(spacing)
            }
        }
    }

    private func calculateColumns(for width: CGFloat) -> Int {
        switch width {
        case 0..<400:
            return 2
        case 400..<600:
            return 3
        case 600..<900:
            return 4
        default:
            return 5
        }
    }
}

struct ParallaxHeaderView: View {
    let title: String
    let imageURL: URL

    var body: some View {
        ScrollView {
            GeometryReader { geometry in
                let offset = geometry.frame(in: .global).minY
                let height = max(200, 200 + offset)
                let opacity = max(0, min(1, 1 - offset / 200))

                AsyncImage(url: imageURL) { image in
                        .resizable()
                        .aspectRatio(contentMode: .fill)
                        .frame(width: geometry.size.width, height: height)
                        .clipped()
                        .offset(y: offset > 0 ? -offset : 0)
                } placeholder: {
                    Rectangle()
                        .fill(Color.gray)
                        .frame(height: height)
                }
                .overlay(
                    LinearGradient(
                        colors: [.clear, .black.opacity(0.7)],
                        startPoint: .top,
                        endPoint: .bottom
                    )
                )
                .overlay(
                    Text(title)
                        .font(.largeTitle)
                        .fontWeight(.bold)
                        .foregroundColor(.white)
                        .opacity(opacity)
                        .padding()
                    , alignment: .bottomLeading
                )
            }
            .frame(height: 200)

            // Content below header
            VStack(alignment: .leading, spacing: 20) {
                Text("Content")
                    .font(.title2)

                ForEach(0..<20) { index in
                    Text("Item \(index)")
                        .padding()
                        .frame(maxWidth: .infinity)
                        .background(Color.gray.opacity(0.1))
                        .cornerRadius(10)
                }
            }
            .padding()
        }
        .edgesIgnoringSafeArea(.top)
    }
}

struct CircularLayout: View {
    let items: [String]

    var body: some View {
        GeometryReader { geometry in
            let center = CGPoint(
                x: geometry.size.width / 2,
                y: geometry.size.height / 2
            )
            let radius = min(geometry.size.width, geometry.size.height) / 2.5

            ZStack {
                ForEach(Array(items.enumerated()), id: \.offset) { index, item in
                    let angle = (2 * .pi / Double(items.count)) * Double(index) - .pi / 2
                    let x = center.x + radius * cos(angle)
                    let y = center.y + radius * sin(angle)

                    Text(item)
                        .font(.headline)
                        .padding()
                        .background(Color.blue)
                        .foregroundColor(.white)
                        .cornerRadius(10)
                        .position(x: x, y: y)
                }
            }
        }
    }
}
1 file · swift Explain with highlit

GeometryReader provides parent view size and coordinates, enabling dynamic layouts that adapt to available space. The reader passes a GeometryProxy with size and coordinate space info. I use it for responsive designs—calculate grid columns based on width, scale elements proportionally, or position overlays precisely. Common use cases include custom scroll effects, circular layouts, and responsive grids. For preference keys, I combine GeometryReader with .preference() to pass child sizes up the view hierarchy. The reader takes all available space, so I wrap it carefully to avoid layout issues. Modern SwiftUI prefers intrinsic sizing, but GeometryReader remains essential for complex custom layouts.
