GraphQL API with Spring Boot

David Kumar Jan 2026

3 tabs

type User {
    id: ID!
    name: String!
    email: String!
    posts: [Post!]!
    createdAt: String!
}

type Post {
    id: ID!
    title: String!
    content: String!
    author: User!
    comments: [Comment!]!
    createdAt: String!
}

type Comment {
    id: ID!
    content: String!
    author: User!
    post: Post!
    createdAt: String!
}

type Query {
    user(id: ID!): User
    users(page: Int = 0, size: Int = 10): [User!]!
    post(id: ID!): Post
    posts(userId: ID): [Post!]!
}

type Mutation {
    createUser(name: String!, email: String!, password: String!): User!
    updateUser(id: ID!, name: String, email: String): User!
    deleteUser(id: ID!): Boolean!
    createPost(userId: ID!, title: String!, content: String!): Post!
}

type Subscription {
    postCreated: Post!
}

package com.example.demo.controller;

import com.example.demo.model.User;
import com.example.demo.model.Post;
import com.example.demo.service.UserService;
import com.example.demo.service.PostService;
import org.springframework.graphql.data.method.annotation.Argument;
import org.springframework.graphql.data.method.annotation.MutationMapping;
import org.springframework.graphql.data.method.annotation.QueryMapping;
import org.springframework.graphql.data.method.annotation.SchemaMapping;
import org.springframework.stereotype.Controller;

import java.util.List;

@Controller
public class UserGraphQLController {

    private final UserService userService;
    private final PostService postService;

    public UserGraphQLController(UserService userService, PostService postService) {
        this.userService = userService;
        this.postService = postService;
    }

    @QueryMapping
    public User user(@Argument Long id) {
        return userService.findById(id)
            .orElseThrow(() -> new RuntimeException("User not found"));
    }

    @QueryMapping
    public List<User> users(@Argument int page, @Argument int size) {
        return userService.findAll(page, size);
    }

    @MutationMapping
    public User createUser(@Argument String name,
                          @Argument String email,
                          @Argument String password) {
        User user = new User();
        user.setName(name);
        user.setEmail(email);
        user.setPassword(password);
        return userService.save(user);
    }

    @MutationMapping
    public User updateUser(@Argument Long id,
                          @Argument String name,
                          @Argument String email) {
        return userService.update(id, name, email);
    }

    @MutationMapping
    public Boolean deleteUser(@Argument Long id) {
        userService.deleteById(id);
        return true;
    }

    // Field resolver - fetches posts for a user
    @SchemaMapping(typeName = "User", field = "posts")
    public List<Post> posts(User user) {
        return postService.findByUserId(user.getId());
    }
}

package com.example.demo.config;

import graphql.scalars.ExtendedScalars;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.graphql.execution.RuntimeWiringConfigurer;

@Configuration
public class GraphQLConfig {

    @Bean
    public RuntimeWiringConfigurer runtimeWiringConfigurer() {
        return wiringBuilder -> wiringBuilder
            .scalar(ExtendedScalars.DateTime)
            .scalar(ExtendedScalars.Json);
    }
}

3 files · graphql, java Explain with highlit

GraphQL provides flexible APIs where clients specify exact data requirements. Spring for GraphQL integrates GraphQL Java with Spring Boot. Schema-first approach defines types in .graphqls files. Resolvers map schema fields to Java methods using @QueryMapping, @MutationMapping. DataLoader prevents N+1 queries through batching. GraphQL enables fetching related data in single request, reducing over-fetching and under-fetching. Subscriptions support real-time updates via WebSocket. Error handling uses DataFetcherExceptionHandler. Pagination uses cursor-based approach. GraphQL excels for complex data requirements, mobile apps, and evolving APIs. The self-documenting schema simplifies frontend development. Spring's annotation-based approach makes GraphQL accessible to Java developers familiar with REST.
