Database schema migrations and versioning

Maria Garcia Feb 2026

2 tabs

-- Migration naming convention: V{version}__{description}.sql
-- Example: V001__create_users_table.sql

-- Migration 1: Create initial schema
-- V001__create_users_table.sql
CREATE TABLE users (
  id SERIAL PRIMARY KEY,
  username VARCHAR(50) UNIQUE NOT NULL,
  email VARCHAR(100) UNIQUE NOT NULL,
  created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP
);

CREATE INDEX idx_users_email ON users(email);

-- Migration 2: Add column (backwards compatible)
-- V002__add_users_status.sql
ALTER TABLE users
  ADD COLUMN status VARCHAR(20) DEFAULT 'active';

-- Migration 3: Populate new column
-- V003__populate_users_status.sql
UPDATE users
SET status = 'active'
WHERE status IS NULL;

-- Migration 4: Add NOT NULL constraint
-- V004__make_status_not_null.sql
ALTER TABLE users
  ALTER COLUMN status SET NOT NULL;

-- Safe column rename (multi-step for zero downtime)

-- Step 1: Add new column
-- V005__add_users_full_name.sql
ALTER TABLE users
  ADD COLUMN full_name VARCHAR(100);

-- Step 2: Copy data
-- V006__populate_full_name.sql
UPDATE users
SET full_name = username
WHERE full_name IS NULL;

-- Step 3: Update application to use full_name
-- Deploy application code

-- Step 4: Drop old column
-- V007__drop_users_username.sql
ALTER TABLE users
  DROP COLUMN username;

-- Idempotent migration (safe to run multiple times)
DO $$
BEGIN
  IF NOT EXISTS (
    SELECT 1 FROM information_schema.columns
    WHERE table_name = 'users' AND column_name = 'phone'
  ) THEN
    ALTER TABLE users ADD COLUMN phone VARCHAR(20);
  END IF;
END $$;

-- Conditional index creation
CREATE INDEX IF NOT EXISTS idx_users_status ON users(status);

-- Transaction-wrapped migration
BEGIN;

CREATE TABLE orders (
  id SERIAL PRIMARY KEY,
  user_id INT REFERENCES users(id),
  total DECIMAL(10,2),
  created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP
);

CREATE INDEX idx_orders_user_id ON orders(user_id);
CREATE INDEX idx_orders_created_at ON orders(created_at);

COMMIT;
-- If any statement fails, all changes are rolled back

-- Data migration with batching (for large tables)
DO $$
DECLARE
  batch_size INT := 1000;
  affected_rows INT;
BEGIN
  LOOP
    UPDATE users
    SET status = 'verified'
    WHERE id IN (
      SELECT id FROM users
      WHERE status = 'active' AND email_verified = true
      LIMIT batch_size
    );

    GET DIAGNOSTICS affected_rows = ROW_COUNT;
    EXIT WHEN affected_rows = 0;

    -- Commit batch and pause
    COMMIT;
    PERFORM pg_sleep(0.1);
  END LOOP;
END $$;

-- Rollback migration (down migration)
-- V002__add_users_status__rollback.sql
ALTER TABLE users
  DROP COLUMN status;

-- Check migration status
-- Flyway command: flyway info
-- Shows: version, description, type, installed on, state

-- Schema version table (Flyway creates this)
SELECT * FROM flyway_schema_history
ORDER BY installed_rank;

-- Liquibase XML changeset example
/*
<?xml version="1.0" encoding="UTF-8"?>
<databaseChangeLog>
  <changeSet id="1" author="maria">
    <createTable tableName="users">
      <column name="id" type="int" autoIncrement="true">
        <constraints primaryKey="true"/>
      </column>
      <column name="username" type="varchar(50)">
        <constraints nullable="false" unique="true"/>
      </column>
    </createTable>
  </changeSet>

  <changeSet id="2" author="maria">
    <addColumn tableName="users">
      <column name="email" type="varchar(100)"/>
    </addColumn>
  </changeSet>

  <changeSet id="3" author="maria" context="prod">
    <sql>
      CREATE INDEX idx_users_email ON users(email);
    </sql>
    <rollback>
      DROP INDEX idx_users_email;
    </rollback>
  </changeSet>
</databaseChangeLog>
*/

-- Rails migration example
/*
class CreateUsers < ActiveRecord::Migration[7.0]
  def change
    create_table :users do |t|
      t.string :username, null: false
      t.string :email, null: false
      t.string :status, default: 'active'
      t.timestamps
    end

    add_index :users, :email, unique: true
    add_index :users, :username, unique: true
  end
end
*/

-- Online schema change for large tables
-- PostgreSQL: pg_repack for zero-downtime table rewrites
-- pg_repack --table=users --no-order

-- MySQL: pt-online-schema-change
-- pt-online-schema-change --alter "ADD COLUMN phone VARCHAR(20)" --   D=mydb,t=users --execute

-- Add column with default without table lock (PostgreSQL 11+)
ALTER TABLE large_table
  ADD COLUMN new_column INT DEFAULT 0 NOT NULL;
-- In PG 11+, default value doesn't rewrite table

-- Concurrent index creation (non-blocking)
CREATE INDEX CONCURRENTLY idx_users_created_at ON users(created_at);
-- Allows reads/writes during index creation

-- Drop index concurrently
DROP INDEX CONCURRENTLY idx_old_index;

-- Schema validation before migration
DO $$
BEGIN
  -- Check table exists
  IF NOT EXISTS (
    SELECT 1 FROM information_schema.tables
    WHERE table_name = 'users'
  ) THEN
    RAISE EXCEPTION 'Table users does not exist';
  END IF;

  -- Check column doesn't exist
  IF EXISTS (
    SELECT 1 FROM information_schema.columns
    WHERE table_name = 'users' AND column_name = 'new_column'
  ) THEN
    RAISE EXCEPTION 'Column new_column already exists';
  END IF;
END $$;

-- Enum type migration (PostgreSQL)
-- Create enum
CREATE TYPE user_status AS ENUM ('active', 'inactive', 'suspended');

ALTER TABLE users
  ADD COLUMN status_enum user_status DEFAULT 'active';

-- Add value to enum
ALTER TYPE user_status ADD VALUE 'archived';

-- Drop enum (must drop dependencies first)
ALTER TABLE users DROP COLUMN status_enum;
DROP TYPE user_status;

-- Foreign key addition (validate separately for zero downtime)
-- Step 1: Add NOT VALID constraint (doesn't lock)
ALTER TABLE orders
  ADD CONSTRAINT fk_orders_user_id
  FOREIGN KEY (user_id) REFERENCES users(id)
  NOT VALID;

-- Step 2: Validate constraint (locks briefly per row)
ALTER TABLE orders
  VALIDATE CONSTRAINT fk_orders_user_id;

-- Partition existing table (PostgreSQL)
-- Create new partitioned table
CREATE TABLE measurements_new (
  id BIGSERIAL,
  sensor_id INT,
  value DECIMAL,
  measured_at TIMESTAMP,
  PRIMARY KEY (id, measured_at)
) PARTITION BY RANGE (measured_at);

-- Create partitions
CREATE TABLE measurements_2024_01 PARTITION OF measurements_new
  FOR VALUES FROM ('2024-01-01') TO ('2024-02-01');

-- Copy data
INSERT INTO measurements_new SELECT * FROM measurements;

-- Swap tables
BEGIN;
ALTER TABLE measurements RENAME TO measurements_old;
ALTER TABLE measurements_new RENAME TO measurements;
COMMIT;

-- Drop old table
DROP TABLE measurements_old;

-- Migration dry-run
BEGIN;
-- Run migration SQL
ALTER TABLE users ADD COLUMN test_column INT;
-- Review changes
SELECT * FROM users LIMIT 1;
-- Rollback
ROLLBACK;

-- Track migration duration
	iming on
-- Run migration
ALTER TABLE large_table ADD COLUMN new_col INT;
	iming off

2 files · sql Explain with highlit

Schema migrations evolve database structure safely. I use migration tools like Flyway, Liquibase, or framework migrations. Version-controlled migrations track schema changes. Up migrations apply changes, down migrations revert. Idempotent migrations can run multiple times safely. I avoid destructive changes—rename, don't drop. Backwards-compatible migrations enable zero-downtime deploys. Multi-step migrations: add column, deploy code, backfill data, add constraint. Transaction-wrapped migrations ensure atomicity. Understanding migration order prevents dependency issues. Blue-green deployments need schema compatibility. Testing migrations in staging catches errors. Migration rollback plans minimize downtime. Proper migration strategy enables continuous database evolution without production incidents.
