Multi-tenancy database patterns and strategies
-- Pattern 1: Shared schema with tenant_id column
CREATE TABLE tenants (
id SERIAL PRIMARY KEY,
name VARCHAR(100) NOT NULL,
slug VARCHAR(50) UNIQUE NOT NULL,
created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP
);
CREATE TABLE users (
id SERIAL PRIMARY KEY,
tenant_id INT NOT NULL REFERENCES tenants(id) ON DELETE CASCADE,
username VARCHAR(50) NOT NULL,
email VARCHAR(100) NOT NULL,
UNIQUE (tenant_id, email)
);
CREATE INDEX idx_users_tenant ON users(tenant_id);
CREATE TABLE orders (
id SERIAL PRIMARY KEY,
tenant_id INT NOT NULL REFERENCES tenants(id) ON DELETE CASCADE,
user_id INT NOT NULL REFERENCES users(id),
total DECIMAL(10,2),
created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
CONSTRAINT fk_order_user_tenant
FOREIGN KEY (tenant_id, user_id)
REFERENCES users(tenant_id, id) -- Ensures same tenant
);
CREATE INDEX idx_orders_tenant ON orders(tenant_id);
-- All queries MUST include tenant_id
SELECT * FROM users
WHERE tenant_id = 123 AND email = 'user@example.com';
-- Set application context (connection-level)
SET app.current_tenant_id = '123';
-- Application ensures tenant_id in all queries
INSERT INTO users (tenant_id, username, email)
VALUES (
current_setting('app.current_tenant_id')::INT,
'newuser',
'new@example.com'
);
-- Pattern 2: Row-Level Security (automatic filtering)
ALTER TABLE users ENABLE ROW LEVEL SECURITY;
ALTER TABLE orders ENABLE ROW LEVEL SECURITY;
-- Policy: Users only see their tenant's data
CREATE POLICY tenant_isolation_users ON users
USING (tenant_id = current_setting('app.current_tenant_id')::INT);
CREATE POLICY tenant_isolation_orders ON orders
USING (tenant_id = current_setting('app.current_tenant_id')::INT);
-- Now queries automatically filter by tenant
SET app.current_tenant_id = '123';
SELECT * FROM users; -- Only tenant 123's users
-- Superuser can see all (for admin queries)
CREATE POLICY admin_all_users ON users
FOR ALL
TO admin_role
USING (true);
-- Force RLS even for table owner
ALTER TABLE users FORCE ROW LEVEL SECURITY;
-- Pattern 3: Separate schema per tenant
-- Create schema for each tenant
CREATE SCHEMA tenant_123;
CREATE SCHEMA tenant_456;
-- Create tables in each schema
CREATE TABLE tenant_123.users (
id SERIAL PRIMARY KEY,
username VARCHAR(50),
email VARCHAR(100)
);
CREATE TABLE tenant_456.users (
id SERIAL PRIMARY KEY,
username VARCHAR(50),
email VARCHAR(100)
);
-- Set search path per connection
SET search_path TO tenant_123, public;
SELECT * FROM users; -- Queries tenant_123.users
-- Schema creation function
CREATE OR REPLACE FUNCTION create_tenant_schema(tenant_slug VARCHAR)
RETURNS VOID AS $$
BEGIN
EXECUTE format('CREATE SCHEMA %I', tenant_slug);
EXECUTE format('
CREATE TABLE %I.users (
id SERIAL PRIMARY KEY,
username VARCHAR(50),
email VARCHAR(100) UNIQUE
)', tenant_slug);
EXECUTE format('
CREATE TABLE %I.orders (
id SERIAL PRIMARY KEY,
user_id INT REFERENCES %I.users(id),
total DECIMAL(10,2)
)', tenant_slug, tenant_slug);
-- Grant permissions
EXECUTE format('GRANT USAGE ON SCHEMA %I TO app_user', tenant_slug);
EXECUTE format('GRANT ALL ON ALL TABLES IN SCHEMA %I TO app_user', tenant_slug);
END;
$$ LANGUAGE plpgsql;
-- Create new tenant
INSERT INTO tenants (name, slug) VALUES ('Acme Corp', 'acme');
SELECT create_tenant_schema('acme');
-- Schema migrations for all tenants
DO $$
DECLARE
tenant_record RECORD;
BEGIN
FOR tenant_record IN SELECT slug FROM tenants LOOP
EXECUTE format('
ALTER TABLE %I.users ADD COLUMN IF NOT EXISTS phone VARCHAR(20)
', tenant_record.slug);
END LOOP;
END $$;
-- Tenant context middleware (application sets this per request)
/*
// Node.js example
app.use(async (req, res, next) => {
const tenantSlug = req.hostname.split('.')[0]; // subdomain
const tenant = await db.query(
'SELECT id FROM tenants WHERE slug = $1',
[tenantSlug]
);
if (!tenant.rows[0]) {
return res.status(404).send('Tenant not found');
}
// Set tenant context for this connection
await req.dbClient.query(
'SET LOCAL app.current_tenant_id = $1',
[tenant.rows[0].id]
);
next();
});
*/
-- Tenant-specific connection pooling
/*
const pools = {};
function getTenantPool(tenantSlug) {
if (!pools[tenantSlug]) {
pools[tenantSlug] = new Pool({
...dbConfig,
options: `-c search_path=${tenantSlug},public`
});
}
return pools[tenantSlug];
}
*/
-- Cross-tenant queries (admin only)
CREATE VIEW all_tenants_users AS
SELECT
t.name AS tenant_name,
t.slug AS tenant_slug,
u.id,
u.username,
u.email,
u.created_at
FROM tenants t
JOIN users u ON t.id = u.tenant_id;
-- Tenant metrics
SELECT
t.name AS tenant,
COUNT(DISTINCT u.id) AS user_count,
COUNT(DISTINCT o.id) AS order_count,
COALESCE(SUM(o.total), 0) AS total_revenue,
pg_size_pretty(
pg_total_relation_size('users') *
COUNT(DISTINCT u.id)::FLOAT /
NULLIF((SELECT COUNT(*) FROM users), 0)
) AS estimated_storage
FROM tenants t
LEFT JOIN users u ON t.id = u.tenant_id
LEFT JOIN orders o ON t.id = o.tenant_id
GROUP BY t.id, t.name
ORDER BY total_revenue DESC;
-- Tenant data export
COPY (
SELECT *
FROM users
WHERE tenant_id = 123
) TO '/backup/tenant_123_users.csv' WITH CSV HEADER;
-- Tenant data deletion (GDPR compliance)
BEGIN;
DELETE FROM orders WHERE tenant_id = 123;
DELETE FROM users WHERE tenant_id = 123;
DELETE FROM tenants WHERE id = 123;
COMMIT;
-- Or with CASCADE
DELETE FROM tenants WHERE id = 123; -- Cascades to users, orders
-- Tenant isolation verification
CREATE OR REPLACE FUNCTION verify_tenant_isolation()
RETURNS TABLE(table_name TEXT, missing_policy BOOLEAN) AS $$
BEGIN
RETURN QUERY
SELECT
t.tablename::TEXT,
NOT EXISTS (
SELECT 1 FROM pg_policies p
WHERE p.tablename = t.tablename
AND p.policyname LIKE 'tenant_isolation%'
) AS missing_policy
FROM pg_tables t
WHERE t.schemaname = 'public'
AND EXISTS (
SELECT 1 FROM information_schema.columns c
WHERE c.table_name = t.tablename
AND c.column_name = 'tenant_id'
);
END;
$$ LANGUAGE plpgsql;
-- Check for tables missing RLS policies
SELECT * FROM verify_tenant_isolation()
WHERE missing_policy = true;
-- Tenant-aware backup script
/*
#!/bin/bash
for tenant_id in $(psql -t -c "SELECT id FROM tenants"); do
pg_dump --data-only --table=users --table=orders --where="tenant_id=$tenant_id" mydb > "tenant_${tenant_id}_backup.sql"
done
*/
-- Schema-based tenant cleanup
DROP SCHEMA tenant_123 CASCADE;
DELETE FROM tenants WHERE slug = 'tenant_123';
-- Tenant onboarding
CREATE OR REPLACE FUNCTION onboard_tenant(
tenant_name VARCHAR,
tenant_slug VARCHAR,
admin_email VARCHAR
)
RETURNS INT AS $$
DECLARE
new_tenant_id INT;
new_user_id INT;
BEGIN
-- Create tenant
INSERT INTO tenants (name, slug)
VALUES (tenant_name, tenant_slug)
RETURNING id INTO new_tenant_id;
-- Create admin user
INSERT INTO users (tenant_id, username, email, role)
VALUES (new_tenant_id, 'admin', admin_email, 'admin')
RETURNING id INTO new_user_id;
-- Create default data
INSERT INTO settings (tenant_id, key, value)
VALUES
(new_tenant_id, 'theme', 'light'),
(new_tenant_id, 'timezone', 'UTC');
RETURN new_tenant_id;
END;
$$ LANGUAGE plpgsql;
-- Use
SELECT onboard_tenant('New Corp', 'newcorp', 'admin@newcorp.com');
-- Tenant query performance
-- Ensure composite indexes include tenant_id first
CREATE INDEX idx_orders_tenant_user ON orders(tenant_id, user_id);
CREATE INDEX idx_orders_tenant_date ON orders(tenant_id, created_at DESC);
-- Partition by tenant (for very large deployments)
CREATE TABLE orders (
id BIGSERIAL,
tenant_id INT NOT NULL,
user_id INT NOT NULL,
total DECIMAL(10,2),
created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
PRIMARY KEY (id, tenant_id)
) PARTITION BY LIST (tenant_id);
CREATE TABLE orders_tenant_1 PARTITION OF orders
FOR VALUES IN (1);
CREATE TABLE orders_tenant_2 PARTITION OF orders
FOR VALUES IN (2);
-- Partition pruning benefits large tenants
Multi-tenancy serves multiple customers from one application. I implement tenant isolation via schemas, databases, or row-level security. Shared schema with tenant_id column is simplest—good indexing essential. Separate schemas per tenant improves isolation, complicates migrations. Separate databases provide maximum isolation but expensive. Row-level security enforces automatic filtering. Understanding tenant data size guides strategy. Connection pooling per tenant prevents resource exhaustion. Tenant context must be set per request. Backup and restore strategies differ by approach. Proper multi-tenancy balances isolation, performance, operational complexity. Essential for SaaS applications, B2B platforms. PostgreSQL RLS makes shared-schema multi-tenancy secure and efficient.
