Kubernetes Services and Ingress for traffic routing

Ryan Nakamura Feb 2026

2 tabs

# ClusterIP Service (internal only)
apiVersion: v1
kind: Service
metadata:
  name: web-app
  namespace: production
  labels:
    app: web-app
spec:
  type: ClusterIP
  selector:
    app: web-app
  ports:
    - name: http
      port: 80
      targetPort: 3000
      protocol: TCP

---
# NodePort Service (external via node ports)
apiVersion: v1
kind: Service
metadata:
  name: web-app-nodeport
  namespace: production
spec:
  type: NodePort
  selector:
    app: web-app
  ports:
    - port: 80
      targetPort: 3000
      nodePort: 30080

---
# LoadBalancer Service (cloud LB)
apiVersion: v1
kind: Service
metadata:
  name: web-app-lb
  namespace: production
  annotations:
    service.beta.kubernetes.io/aws-load-balancer-type: nlb
    service.beta.kubernetes.io/aws-load-balancer-scheme: internet-facing
spec:
  type: LoadBalancer
  selector:
    app: web-app
  ports:
    - port: 443
      targetPort: 3000
      protocol: TCP

---
# Headless Service (for StatefulSets / direct pod DNS)
apiVersion: v1
kind: Service
metadata:
  name: db-headless
  namespace: production
spec:
  clusterIP: None
  selector:
    app: database
  ports:
    - port: 5432
      targetPort: 5432

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-app-ingress
  namespace: production
  annotations:
    nginx.ingress.kubernetes.io/ssl-redirect: "true"
    nginx.ingress.kubernetes.io/rate-limit: "100"
    nginx.ingress.kubernetes.io/proxy-body-size: "10m"
    nginx.ingress.kubernetes.io/enable-cors: "true"
    cert-manager.io/cluster-issuer: letsencrypt-prod
spec:
  ingressClassName: nginx
  tls:
    - hosts:
        - app.example.com
        - api.example.com
      secretName: app-tls-secret
  rules:
    - host: app.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: web-app
                port:
                  number: 80
    - host: api.example.com
      http:
        paths:
          - path: /v1
            pathType: Prefix
            backend:
              service:
                name: api-v1
                port:
                  number: 80
          - path: /v2
            pathType: Prefix
            backend:
              service:
                name: api-v2
                port:
                  number: 80

---
# NetworkPolicy - restrict traffic
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: web-app-netpol
  namespace: production
spec:
  podSelector:
    matchLabels:
      app: web-app
  policyTypes:
    - Ingress
    - Egress
  ingress:
    - from:
        - namespaceSelector:
            matchLabels:
              name: ingress-nginx
      ports:
        - protocol: TCP
          port: 3000
  egress:
    - to:
        - podSelector:
            matchLabels:
              app: database
      ports:
        - protocol: TCP
          port: 5432
    - to:
        - podSelector:
            matchLabels:
              app: redis
      ports:
        - protocol: TCP
          port: 6379
    - to: # Allow DNS
        - namespaceSelector: {}
      ports:
        - protocol: UDP
          port: 53

2 files · yaml Explain with highlit

Kubernetes Services provide stable networking for ephemeral Pods. A ClusterIP service exposes Pods internally within the cluster. NodePort opens a static port on every node for external access. LoadBalancer provisions a cloud load balancer. Services use selector labels to discover target Pods. The targetPort maps to the container port, while port is the service port. Ingress resources route external HTTP/HTTPS traffic to services based on host and path rules. Ingress controllers like nginx-ingress or traefik implement the routing. TLS termination uses secretName referencing a TLS certificate Secret. Path-based routing directs different URLs to different services. Annotations configure controller-specific behavior like rate limiting and CORS.
